| ID |
Date |
Author |
Type |
Subject |
Text |
 |
|
1
|
Tue Apr 19 19:09:25 2016 |
James Bynes | Instructions | Obtaining data from XRM development boardstack | Here are the instructions to obtain data from
XRM boardstack. This has currently been tested
with 1 carrier board, but little modifications |
|
|
2
|
Sun May 1 01:45:45 2016 |
James Bynes | Instructions | Setting up Ubuntu 14.04 to take data from XRM boardstack | This ELOG shows how to obtain data from XRM
boardstack from a fresh install of Ubuntu
14.04
|
|
|
3
|
Tue May 3 08:11:06 2016 |
M. Andrew | documentation | what was done in January 2016 | Here is a data dump of everything that
happened on the asus laptop while getting
the laste 2015 / early 2016 incarnation of |
19x |
|
4
|
Sat May 7 20:52:24 2016 |
James Bynes III | Instructions | Plotting data from XRM boardstack |
[SIZE=3]The following package will allow
you to parse binary data from TargetX and |
|
|
5
|
Tue May 17 16:03:12 2016 |
Gary Varner | report | compilation log | Following up on James` suggestion, have
posted transcript of compilation log below.
Not sure if there is anything should |
|
|
6
|
Wed May 18 01:13:55 2016 |
Chris Ketter, Gary Varner | analysis | first data sets | After getting data logging earlier in the
day, Chris installed the detector and we
took a look at data. |
6x |
|
7
|
Wed May 18 21:32:21 2016 |
Gary Varner | noise during RF conditioning(?) | carrier 0, asic 0 | There is bursts of noise seen in the longer
record lengths (1).
Some channels are quieter (2), |
|
|
8
|
Thu May 19 02:08:09 2016 |
Gary Varner | analysis | statistics during RF on run | Summary statistics for short [1 run @ 64
windows] (1) and longer [100x] (2) show rather
similar responses, where channels 6&7 |
|
|
9
|
Thu May 19 13:49:23 2016 |
Gary Varner | data taking problem report | morning 20-MAY-2016 JST | After beam came back on overnight, wanted
to get a background reference data set.
However when trying to log data |
|
|
10
|
Thu May 19 19:48:14 2016 |
John Flanagan, Gary Varner | network documentation | APC network configuration |
host name : psxrd08
IP address :
172.19.62.89
MAC address: 00:c0:b7:b8:94:f9
> SuperKEKB ネットワーク |
|
|
11
|
Thu May 19 23:01:35 2016 |
Gary Varner | analysis | first try | Started a 1Hz run and let it run, the tail
end of which might have had the detector
in the xray beam. |
|
|
12
|
Fri May 20 16:08:46 2016 |
John Flanagan, Gary Varner | hardware documentation | APC and PDU AC-power settings | Controlling remotely via separate laptop,
with connections on the 2 subnets .0
and .1 |
|
|
13
|
Fri May 20 23:30:23 2016 |
Chris Ketter | information | Configuration of XRM | Attachment 1 is a block diagram of
the XRM setup for the Low Energy Ring (LER).
Physically, this is located underneath the |
|
|
14
|
Sat May 21 01:02:13 2016 |
John Flanagan, Gary Varner | run report | First Light! | After a battle to sort out the networking
issues with the APC (on loan) and PDU, able
to get all working fine, and logged in separate |
|
|
15
|
Tue Jan 22 07:56:56 2019 |
M. Andrew | documentation | instructions for setup, compiling and data acquisition | File XRM.instructions.txt
gives the 2019-era details on running the
XRM. |
|
|
16
|
Tue Jun 18 11:29:30 2019 |
M. Andrew | documentation | raspberry pi | to install:
cd
mkdir -p build |
|
|
17
|
Mon Sep 30 09:36:16 2019 |
M. Andrew | documentation | measurements of accelerator clock and revolution marker | Following Nuclear Instruments and Methods
in Physics Research A 499 (2003) 138–166,
we know that the distributed accelerator |
|
|
18
|
Mon Sep 30 10:59:35 2019 |
M. Andrew | documentation | Althea/RAFFERTY | The firmware running on Althea/RAFFERTY
https://github.com/mzandrew/hdl/blob/master/verilog/src/mza-test032.pll_509divider_and_revo_encoder_plus_calibration_serdes.althea.v
takes a 508.8875 MHz clock input, and uses |
|
|
19
|
Fri Oct 4 08:55:23 2019 |
M. Andrew | documentation | instructions for pdu control | Control of the power distribution unit (pdu)
is done from xrd04rp2. The script pdu.sh
is in the $PATH.
|
|
|
20
|
Fri Oct 4 10:04:12 2019 |
M. Andrew | documentation | instructions for programming boardstack | Programming the boardstack is done from xrd04rp2.
The script boardstack.sh is in the $PATH.
|
|
